    LED Tape WiringDriver Pins & ConfigurationLED Tape Wiring

    The configuration and pin out connections of the SRPC2108 depend on the color output of the LED tape being used.


    Driver Pins & Configuration

    Colors+1-2-3-4-CHDP
    Single WhitePower WireNegative Wire 011.1
    Bi-WhitePower WireWarm WhiteCold White 011.1
    RGBPower WireRedGreenBlue 011.1
    RGBWPower WireRedGreenBlueWhite011.1

    The number of wires connected to the driver depends on the tape color:

    RGBW requires 5 conductors.

    RGB requires 4 conductors.

    Bi-White requires 3 conductors.

    Single White requires 2 conductors.


    LED Tape Wiring

    Make sure to check the soldering pads to see which one powers what color. Wire color may differ.
